5/1/1 programmable
Easy menu driven programming
Intuitive wake, leave, return, sleep programming icons
4 sq. inch display
Blue backlight
Glow in the dark light button
Easy access battery compartment
Electric or Gas configurable
Separate B & O terminals
Separate heating and cooling swing (cycle rate) adjustments
Room temperature calibration adjustment
5 minute compressor delay protection (selectable on or off)
Simple private label badge system
Easy wire color coded terminal blocks
Universal sub-base
Mounts on wall or junction box
Battery or 24v power
5 year warranty
The display range of temperature: 41 to 95 degress F
The control range of temperature: 44 to 90 degrees F
Load Rating: 1 amp per terminal, 1.5 amp max all terminals combined
Display accuracy: +/- 1 degree F
Swing (cycle or differential): Heating is adjustable from 0.2 to 2.0 degrees F
Swing (cycle or differential): Cooling is adjustable from 0.2 to 2.0 degrees F
Power Source: 18 to 30 VAC, NEC Class II, 50/60Hz for hardwire
Power Source: Battery power from 2 AA batteries
Operating ambient: 32 to +105 degrees F
Operating Humidity: 90% non-condensing max
Dimensions of thermostat: 4.7"W x 4.4"H x 1.1"D
Heating
